Silver Flake

这里可以自定义设置
Silver Flake
B站不支持收货地址
B站不支持库存规格
Product name:
Silver Flake
Brand:
Entrepreneur
Cas No.:
7440-22-4
Grade:
AT-AgF-3C / AT-AgF-3A
Country of Origin:
China
Other names:
Flaky silver powder
Flake silver powder
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
该产品后台详情无内容

Description

AT-AgF-3C and AT-AgF-3A flake silver powders have the characteristics of easy dispersion and good conductivity. They are mainly used as conductive fillers in low-temperature curing type conductive pastes, polymer conductive silver pastes, silver pastes for chip components, and conductive adhesives. Small flake diameter silver powders can also be used in mid-to-high temperature sintering type conductor pastes, such as silver pastes for the backside of solar cells and touch screen silver pastes.

这里可以自定义设置

Specifications

Grades

Average particle

size (μm)

Bulk density

(g/cm3)

Tapped density

(g/cm3)

Specific surface

area (m²/g)

Loss on ignition

(540℃, 1hr)

AT-AgF-3C

2.0-5.0

0.8-1.4

1.8-3.0

0.7-1.4

≤0.9

AT-AgF-3A

5.0-10.0

1.6-2.5

2.5-4.0

0.3-0.6

≤0.65

SEM image of  AT-Ag-3C

SEM image of  AT-Ag-3A
